Green Building, Low Carbon Emission
| Place of Origin: | China |
|---|---|
| Brand Name: | Runpaq |
| Certification: | NONE |
| Model Number: | 8031-DN15FF |
| Minimum Order Quantity: | 1000 pieces |
| Price: | USD3.59/piece (>1000pcs) / USD4.31/piece (50-1000 pcs) |
| Packaging Details: | box + maste carton + pallet |
| Delivery Time: | 15-21 days |
| Payment Terms: | L/C, T/T, D/A, D/P, Western Union |
| Supply Ability: | 200000 sets/month |
| Diameter: | DN15, DN20, DN25, Two Way Ball Valve | Work Pressure: | 16 Bar / 1.6 Mpa / 232 Psi / PN16 |
|---|---|---|---|
| Connect: | FNPT Both End, FNPT-NPT | Valve Body Material: | Brass, Stainless Steel SS304, 316 |
| Product Name: | Heat Meter Control Ball Valve/ Cooling Meter Valves | Life Cycle: | >100,000 Times |
| High Light: | 232 psi water meter ball valve,DN15 water meter ball valve,motorised diverter valve |
||
DC Mini Motorized Zone Valve, DN15 Brass Heat Meter valve for heat supply system
Product Description
The zone control valve are consisted by: mini motorized ball valve and DC / AC synchronous geared motor acturator. Through simple wiring, the zone control valve can be opened or closed to regulate the heat metering or cold metering. It's widely applied in: heating supply system, HVAC, air conditioning system, prepay water meter, etc.
Application
Advantages
| No | Name | Material | Advantage |
| 1. | O-ring | Import | Resistance to high temperature, oil, corrosion, chemicals, Work temp.: —30℃+280℃.Quadruple seals, minimize the risk of leakage. |
| 2. | Drainage | Drain just in case leakage happens | |
| 4 | 0-ring | EPDM (red) | Between nut and valve body, extra external leak proof, reduce the possibility of internal leak |
| 8. | Ball | Brass or SS304 | Finely polished, rack nickel plating (not barrel plating), smooth surface, improved torque performance |
| 9. | Water proof G | Avoid water into housing, seal between valve body and valve housing |
| No | Name | Material | Advantages |
| 5. | Wall thickness | 2.0mm, PN20 | |
| 6. | Teflon washer | Import teflon | 1. Import teflon tube, numerical processing to perfectly match with ball surface |
| 7 | 0-ring | EPDM | 1. Good elasticity, as buffer after Teflon washer to improve seal effect |
