Place of Origin: | China |
---|---|
Brand Name: | Runpaq |
Certification: | NONE |
Model Number: | 8065-side |
Minimum Order Quantity: | 1000 pieces |
Price: | USD3.59/piece (>1000pcs) / USD4.31/piece (50-1000 pcs) |
Packaging Details: | box + maste carton + pallet |
Delivery Time: | 15-21 days |
Payment Terms: | L/C, T/T, D/A, D/P, Western Union |
Supply Ability: | 200000 sets/month |
Work Pressure: | 16 Bar / 1.6 Mpa / 232 Psi / PN16 | Connect: | FNPT Both End, FNPT-NPT |
---|---|---|---|
Valve Body Material: | Brass, Stainless Steel SS304, 316 | Product Name: | Motorized Water Valve, Motorised Control Valve |
Life Cycle: | >100,000 Times | Usage: | Underfloor Heating System, Hydronic Heating System, HVAC |
Temperature Of Media: | Medium Temperature, Normal Temperature, High Temperature, Low Temperature | Media: | Water, Oil, 50% Glycol, Steam |
High Light: | pN15 Motorised Zone Valve,Stainless Steel Motorised Zone Valve,pN15 straight radiator valves |
heating systems zone valves replacement, PN15 AC/DC motorised zone valves
Product Description
Our motorized control valve is made of brass or stainless steel, which is a direct motor actuated valve designed for operation in heating system, liquid makeup, temperature, pressure and level control applications for a wide variety of refrigerants. The DC step motor actuator is controlled through thermostat.
Application
Advantages
No | Name | Material | Advantage |
1. | O-ring | Import | Resistance to high temperature, oil, corrosion, chemicals, Work temp.: —30℃+280℃.Quadruple seals, minimize the risk of leakage. |
2. | Drainage | Drain just in case leakage happens | |
4 | 0-ring | EPDM (red) | Between nut and valve body, extra external leak proof, reduce the possibility of internal leak |
8. | Ball | Brass or SS304 | Finely polished, rack nickel plating (not barrel plating), smooth surface, improved torque performance |
9. | Water proof G | Avoid water into housing, seal between valve body and valve housing |
No | Name | Material | Advantages |
5. | Wall thickness | 2.0mm, PN20 | |
6. | Teflon washer | Import teflon | 1. Import teflon tube, numerical processing to perfectly match with ball surface |
7 | 0-ring | EPDM | 1. Good elasticity, as buffer after Teflon washer to improve seal effect |
