| Place of Origin: | China |
|---|---|
| Brand Name: | Runpaq |
| Certification: | NONE |
| Model Number: | K10-DN80/100 |
| Minimum Order Quantity: | 1000 pieces |
| Price: | USD2.28/piece (>2000 pieces) USD2.5 / piece (1000 - 2000 pieces) |
| Packaging Details: | carton |
| Delivery Time: | 15-21 days |
| Payment Terms: | T/T, L/C, D/A, D/P, Western Union |
| Supply Ability: | 200000 sets/month |
| Rated Voltage: | DC3.6V | Voltage Range: | DC2.5V - DC5V |
|---|---|---|---|
| Work Current At 3.6V: | <50 MA (23 C) | Current At Max Loading: | About 1100 MA |
| Motor: | Geared Synchornized Step Motor #320 | Torque: | 25 NM |
| Open / Close Time: | < 90 S | Reduction Ratio: | 10000 : 1 (For DN80 , DN100) |
| Product Name: | Ball Valve Actuator Motor For DN32 | Model: | K10 |
| High Light: | DN80 zone valve motor,DN80 synchron valve motor,DC5V synchron valve motor |
||
electric zone valve motor, motorized ball valve actuator products for DN80 pipe
Product description
For large diameter pipe and applications where higher torque is needed, our K10 geared motor actuator can be recommended. Our DC electric actuator motors can be attached to irrigation water meter, IC card prepay water meter, heat meter, motorized ball valve to control the electric ball valve open or close. The synchronous geared motor is an electric motor actuator in which, at steady state, the rotation of the shaft is synchronized with the frequency of the supply current; the rotation period is exactly equal to an integral number of electric cyles.
Technical data-Model K09
1. Voltage: DC3.6 V (Range: DC2.5 - 5 V, the higher the voltage, the larger torque, the shorter life span)
2. Current at idle: <50 mA @ 3.6V, 23ºC
3. Current with max loading: <1100 mA (motor #500)
4. Torque: >25 NM
5. Open/close time: <90S
6. Velocity reduction ratio: 10000:1 (for DN80 / DN100 ball valve)
7. Protection: IP0
Wiring definition
| No | Color of wire | Definition |
| 1 | blue | on position signal, valve open |
| 2 | white | on position signal, public |
| 3 | yellow | on position signal, valve close |
| 4 | black | positive (+) |
| 5 | red | negative (-) |
