230VAC Hot Water Mixing Valve IP65 Protection Time Control In Fluid Recirculation

230VAC Hot Water Mixing Valve IP65 Protection Time Control In Fluid Recirculation
230VAC Hot Water Mixing Valve IP65 Protection Time Control In Fluid Recirculation 230VAC Hot Water Mixing Valve IP65 Protection Time Control In Fluid Recirculation 230VAC Hot Water Mixing Valve IP65 Protection Time Control In Fluid Recirculation 230VAC Hot Water Mixing Valve IP65 Protection Time Control In Fluid Recirculation 230VAC Hot Water Mixing Valve IP65 Protection Time Control In Fluid Recirculation 230VAC Hot Water Mixing Valve IP65 Protection Time Control In Fluid Recirculation
Basic Information
Place of Origin: China
Brand Name: Runpaq
Certification: NONE
Model Number: TCV15
Minimum Order Quantity: 1000 pieces
Price: USD14/piece (500-1000 pieces) , USD10.5 (>1000 pieces)
Packaging Details: carbon + pallet
Delivery Time: 15-21 days
Payment Terms: D/P, T/T, L/C, D/A, Western Union
Supply Ability: 200000 sets/month
Get Best Price Contact Now
Valve Body Material: CASTING, STAINLESS STEEL, BRASS, PLASTIC, UPVC Work Current: <100 MA
Work Voltage: DC3-6V / DC12V / AC85-230VAC Pressure Rating: Low Pressure, Medium Pressure, High Pressure
Open / Close Time: <5 S Torque: 2 NM
Power: 3 W Protection: IP65
Application: General, Temperature Control, HVAC, Product Name: Time Control Valve, Valve Component, Valve Flap
High Light:

230VAC hot water mixing valve

,

IP65 hot water mixing valve

,

IP65 Time control valve

Set Temperature Control Valves, Hot water mixing valve in hot water recirculation



Product description

An electronic timer, is also called: time control valve, set it to open automatically at specified time interval. These drain valves are exellent for regularly watering the flowers, humidify, drain the equipment, etc. The control mode is timer count down.



Usages

  • Regularly watering the flowers, regularly humidify, and regularly drain the equipment
  • Industrial automatic control small equipment, automatic control system

Features

  • The POM gear and the metal gear are used to cooperate with each other, and the POM gear is used to reduce the noise of gear transmission at the high speed, and the metal gear is adopted at low speed to ensure the reliability of the gear
  • Long service life, more than 100,000 switches
  • Integrated design of electrical limit and mechanical limit, accurate positioning, high consistency, and eliminate the possibility of the actuator connecting
  • The actuator and valve can be assembled in multiple angles to facilitate the allocation of space
  • The ball valve adopts the floating seal structure, no leakage, which is suitable for heavy dirt and long period of no action.

Our advantages

  • More than 50 types, diameter ranges from DN15 to DN40, it features small torque, low electricity consumption,leak-proof, high pressure rating.
  • Customized production available, thanks to our strong mechanical machining and milling capability
  • Sturday valve body with reasonable structure design, and best material to be used
No Name Material Advantage
1. O-ring

Import

fluoro rubber (green)

 Resistance to high temperature, oil, corrosion, chemicals, Work temp.: —30℃+280℃.Quadruple seals, minimize the risk of leakage.
2. Drainage   Drain just in case leakage happens
4 0-ring EPDM (red) Between nut and valve body, extra external leak proof, reduce the possibility of internal leak
8. Ball Brass or SS304 Finely polished, rack nickel plating (not barrel plating), smooth surface, improved torque performance
9. Water proof G   Avoid water into housing, seal between valve body and valve housing
No Name Material Advantages
5. Wall thickness   2.0mm, PN20
6. Teflon washer Import teflon

1. Import teflon tube, numerical processing to perfectly match with ball surface

2. Minimal deformation, polish surface, wearable
7 0-ring EPDM

1. Good elasticity, as buffer after Teflon washer to improve seal effect

2. Reasonable structure design, ensures perfect holding margin

230VAC Hot Water Mixing Valve IP65 Protection Time Control In Fluid Recirculation 0     230VAC Hot Water Mixing Valve IP65 Protection Time Control In Fluid Recirculation 1



Product dimensions

Valve body material Connection port Diameter D L H W
(mm) (Kg)
Brass Both female thread full diameter DN8 8 46 31 0.287
DN15 15 57 38 0.363
DN20 20 71 45 0.444
DN25 23.5 72 49 0.533
3-way vertical DN15 12 63 49 0.365
DN20 15 66 53 0.422
Both female threaded reduced diameter DN10 8 46 31 0.286
DN20 15 66 38 0.378
DN25 20 72 47 0.538
DN32 25 86 60 0.75
Female-male threaded full diameter DN15 15 63 38 0.362
Female-male threaded reduced diameter DN20 15 66 38 0.392
  DN32 20 76 50 0.624
Both male thread DN15 15 68 38 0.354
Stainless steel Both female threaded full diameter DN8 8 46 31 0.294
DN15 15 55 38 0.37
DN20 20 71 45 0.438
DN25 25 72 49 0.547
Both female threaded reduced diameter DN10 8 46 30.5 0.298
DN20 15 63 39 0.443
DN25 20 75 47 0.538



Wiring (DC24V)

230VAC Hot Water Mixing Valve IP65 Protection Time Control In Fluid Recirculation 2



Applications range

  • HVAC, heating supply systems
  • Air conditioning systems
  • Baseboard/radiant heating
  • Convectors
  • Fan coil units
  • Floor heating
  • Unit ventilators
  • VAV reheat
